320561
Manufacturer:
TE Connectivity
Mfr.Part #:
320561
Datasheet:
Description:
Terminals Free Hanging 14 AWG Female
| Parameter | Value |
|---|---|
| Length | 17.86 mm |
| Width | 6.35 mm |
| Termination | Crimp |
| Max Operating Temperature | 105 °C |
| Min Operating Temperature | -55 °C |
| Voltage Rating (AC) | 300 V |
| Material | Copper |
| Packaging | Reel |
| Voltage Rating | 300 V |
| Depth | 6.35 mm |
| Thickness | 787.4 µm |
| Radiation Hardening | No |
| RoHS | Compliant |
| REACH SVHC | No SVHC |
| Contact Plating | Tin |
| Contact Material(Contact Finish) | Copper |
| Type | Ring |
| Orientation | Straight |
| Lifecycle Status | Production (Last Updated: 2 weeks ago) |
| Color | Blue |
| Gender | Female |
| ELV | Compliant |
| Body Material | Copper |
| Wire/Cable Diameter | 3.81 mm |
| Wire/Cable Gauge | 14 AWG |
| Insulation | Insulated |
| Thread Size | M3.5 |
| Insulation Material | Nylon |
| Wire Gauge (Max) | 16 AWG |
| Wire Gauge (Min) | 14 AWG |
| Plating | Tin |
| Termination Style | Crimp |
| Insulation Diameter | 3.81 mm |
| Body Plating | Tin |
| Insulated Wire Support | Yes |
| Manufacturer Lifecycle Status | ACTIVE (Last Updated: 2 weeks ago) |
| Sealable | No |
| Stud Diameter | 3.68 mm |
| Heavy Duty | No |
| Number of Holes | 1 |
| Stud Size | M3.5 |
| Tongue Thickness | 790 µm |
| Government Qualified | Yes |
Stock: 4705
Distributors
pcbx
pcbxUnit Price$0.25050
Ext.Price$0.25050
| Qty | Unit Price | Ext.Price |
|---|---|---|
| 1 | $0.25050 | $0.25050 |
| 10 | $0.21287 | $2.12870 |
| 50 | $0.18448 | $9.22400 |
| 100 | $0.15987 | $15.98700 |
| 500 | $0.14318 | $71.59000 |
| 1000 | $0.12824 | $128.24000 |
| 3000 | $0.12226 | $366.78000 |
| 5000 | $0.12140 | $607.00000 |
| 10000 | $0.12054 | $1205.40000 |
